ABS Plain Standard Ball Valve -Single Union
In stock
Only %1 left
SKU
011.82S1.02Q
| Enable Hide Price | No |
|---|
Description
ABS Standard Single Union Ball Valve has a union on one end of the fitting, allowing for easy pipe disconnection for quick maintenance while the opposite end of the fitting is fixed in place.
| d | L | Z | H | A | B | C | E | F |
|---|---|---|---|---|---|---|---|---|
| 3/8” | 14 | 44 | 72 | 50 | 10 | 58 | 39 | 21 |
| 1/2” | 16 | 44 | 76 | 50 | 10 | 58 | 39 | 21 |
| 3/4” | 19 | 52 | 90 | 60 | 11 | 65 | 47 | 24 |
| 1” | 22 | 58 | 102 | 68 | 13 | 75 | 55 | 27 |
| 1 1/4” | 26 | 66 | 118 | 80 | 18 | 75 | 60 | 30 |
| 1 1/2” | 31 | 74 | 136 | 96 | 20 | 87 | 68 | 35 |
| 2” | 38 | 92 | 168 | 116 | 20 | 101 | 80 | 40 |
| 2 1/2” | 44 | 126 | 214 | 145 | 25 | 123 | 90 | 45 |
| 3” | 51 | 138 | 240 | 166 | 28 | 138 | 100 | 50 |
| 4” | 61 | 153 | 275 | 210 | 28 | 160 | 120 | 60 |
The Illustration and Specifications provided are not guaranteed and may vary depending on Brand or Manufacturer.
